Product Description

l High extinction ratio: >10000:1, >100000:1

l Optical element material: Calcite, α-BBO

l Operating wavelength: 200 nm-3.0 μm

l Air-gap structure

l Side frosted, no escape window

     Tuniu Glan-Taylor Crystal Polarizing Prisms are composed of two prisms made of the same type of negative uniaxial crystal (no > ne) with their optical axes parallel to each other, and can be used to output linearly polarized light with high extinction ratio. The Glan-Taylor crystal polarizing prism features an air-gap structure in the middle, with frosted side surfaces, and is pre-installed in a black anodized mechanical housing. The Glan-Taylor crystal polarizing prism does not have an escape window on the side, so it is designed thinner compared to the Glan-Laser crystal polarizing prism and is not suitable for high-power applications. Currently, Tuniu Glan-Taylor crystal polarizing prisms are available in two clear apertures (Ø10 mm and Ø5 mm) and four operating wavelength ranges (350 nm-2.3 μm, 200 nm-300 nm, 300-700 nm, 700 nm-3.0 μm). Additionally, Tuniu offers customization services for operating wavelengths and dimensions. For customization requirements, please contact Tuniu technical support.

Attributes

Glan-Taylor Calcite Polarizing Prism, Ø5 mm

l Working wavelength: 220 nm-2.3 μm (segmented)

     Tuniu Glan-Taylor crystal polarizing prisms are used to output linearly polarized light with high extinction ratio. Tuniu offers Glan-Taylor crystal polarizing prisms with clear apertures of Ø5 mm and operating wavelengths of 350 nm-2.3 μm (AR coating 1064 nm), 220 nm-300 nm (AR coating 245 nm), and 300 nm-700 nm (AR coating 532 nm). Tuniu Glan-Taylor crystal polarizing prisms are pre-installed in a black anodized mechanical housing and are not detachable. One end of the housing is engraved with SM05 external threads and comes with a retaining ring, which can be reversely locked to control the polarization direction of the prism. The other end is a smooth wall, both of which can be used with Tuniu adjustment mounts for convenient customer use.

Glan-Taylor Calcite Polarizing Prism, Ø10 mm

l Working wavelength: 200 nm-3.0 μm (segmented)

     Tuniu Glan-Taylor crystal polarizing prisms are used to output linearly polarized light with high extinction ratios. Tuniu offers Glan-Taylor crystal polarizing prisms with clear apertures of Ø10 mm and operating wavelengths of 350 nm-2.3 μm (AR coating 1064 nm), 200 nm-300 nm (AR coating 245 nm), 300 nm-700 nm (AR coating 532 nm), and 700 nm-3.0 μm (AR coating 1064 nm). Tuniu Glan-Taylor crystal polarizing prisms are pre-installed in a black anodized mechanical housing that is not detachable. One end of the housing is engraved with an SM1 external thread and includes a retaining ring, which can be reverse-locked to control the polarization direction of the prism. The other end is a smooth wall, both of which can be used with Tuniu adjustment mounts for convenient customer use.
